コームバンドパスフィルター

S/N

Item

Parameters

1

Center Frequency(F0)

3000MHz

2

Pass Band Frequency

2500 ~ 3500MHz ^**

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.6dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 2260MHz

≥40dB @ 2260 ~ 2400MHz

≥55dB @ 3600 ~ 3650MHz

≥80dB @ 3650 ~ 9000MHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

0℃ ~ +50℃

12

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Connectors: Stainless Steel

Other screw: Stainless Steel

13

Dimensions

170*22*21mm

14

Net weight

0.15 KG
