캐비티 밴드 스톱 필터

S/N

Item

Parameters

1

Stop Band Frequency

2570 ~ 2690MHz

2

Stop Band Attenuation

≥40dB

3

Pass Band Frequency

DC ~ 2540MHz , 2720 ~ 6400MHz

4

Pass Band Insertion Loss

≤2.0dB

5

Pass Band VSWR

≤1.5:1

6

Impedance

50 Ohms

7

Power

50W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-20℃ ~ +60℃

11

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Connectors: Stainless Steel

Other screw: Stainless Steel

12

Dimensions

209*36*22mm

13

Net weight

0.345 KG
