Filtro passa banda pettine

S/N

Item

Parameters

1

Center Frequency(F0)

33GHz

2

Pass Band Frequency

26 ~ 40GHz ^**

3

Pass Band Insertion Loss

≤1.05dB

4

Pass Band Ripple

≤0.47dB

5

Pass Band Return Loss

≥17dB (Typical: ≥18dB)

6

Stop Band Rejection

≥80dB @ DC ~ 23.7GHz

≥38dB @ 23.7 ~ 25GHz

≥32dB @ 41 ~ 42.3GHz

≥80dB @ 42.3 ~ 58GHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

2.92mm(K)-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃

12

Material

Housing: H62 Copper alloy

Cover: H62 Copper alloy

Tuning screw: H62 Copper alloy

Connectors: Stainless Steel

Other screw: Stainless Steel

13

Dimensions

60*14*7.7mm

14

Net weight

0.047 KG
